Pneumatic Feeder Changing to Electric Feeder Type in SMT Industry

Description

With the development of new energy vehicles, 5G, A1 and the Internet of Things, the demand for high-precision and high-reliability SMT processes will continue to increase. Pneumatic feeder changing to electric feeder completely solve the traditional problems of the old pneumatic feeder, such as material throwing, easy wear and short service life. More powerful, smarter and more stable in function!

Advantage（JUKI electric Feeder as an example）

1.All mechanical platforms are compatible.

2.Electric feeder is compatible with the pneumatic feeder.

3.The material throwing rate is as low as two ten-thousandths.

4.The mechanical suction of materials is always synchronized.

5.The core components have a service life of up to five years, and the dual-motor drive is precise and stable. Imported dual motor drive. Both feeding and stripping adopt the design concept of FUJI NXT II generation feeder to achieve synchronous collaboration of dual motors. The feeding speed and accuracy of feeder have been greatly improved, and common production problems such as difficult tearing of the material film and no material belt movement have been avoided.

6.The coordinate absorption can be fine-tuned on the Feeder, thereby achieving the effect of the equipment's placement head taking materials simultaneously.

The production capacity of the KE200 series has been increased by 10%, and that of the FX series has been increased by 15%.

7.Genuine materials; Durable and long-lasting

The pressure cover is made of high-hardness copper to prevent the material from overturning and spilling due to static electricity. The newly installed tail enables the convenience of changing materials without stopping the machine. The body is made of high-strength materials, which will not deform for a long time and is more durable!

8.The revolution of domestic feeder

High-strength materials; Durable and non-deformable, imported grade motor; Precise and stable material feeding; Safe voltage control, safe, efficient and stable, intelligent control system, achieving the precision of mounting 0201, strong versatility, all machines using JUKI pneumatic feeder can use it.

In a word, electric feeder suitable for use in high-precision and high-speed surface mount technology (SMT) machines, which high speed and high stability production efficiency are required. This is the content Yangling Electronics mainly talking about. If you want to know about it, please contact Nancy. Thank you.
